These item is a M12 x 1.25mm Standard Pitch Right Hand Thread, Male to Female High Performance, High Misalignment Angle Ball Joint - ideal for use in all types of motorsport or Kit Car type applications such as linkages and Anti Roll Bar Links etc
Supplied with a fine thread pitch (1.25mm) M12 internal and External thread , this ball joint is rated to a Radial Static Load of 37.5 KN , these Ball Points are made from heat treated carbon Steel which is protective coated for corrosion resistance.
Male thread to opposite end of rod - 58mm
female thread to opposite end of rod - 66.8mm
Width at widest point - 33.1mm
length of male thread - 17.4mm
They also are zero maintenance as they come pre-lubricated.
Perfect for all general forms of Motorsports.
